It's a fake volcano that spits mud!

Mud volcano is a unique geological phenomenon. Its shape is similar to that of volcanoes formed by magma, but the materials erupted by mud volcanoes are mainly mud, water and gas (such as methane, carbon dioxide, etc.), rather than hot magma. Therefore, mud volcanoes like to "spit" mud seriously, and they are actually "fake" volcanoes!

There are many classifications of mud volcanoes. According to their shapes, they can be divided into accumulation cone type, concave basin type and semi-accumulation cone concave basin type; according to the height of the cone, they can be divided into large, medium and small types; according to their geographical location, they can be divided into land and submarine mud volcanoes; they can also be divided according to the size of the mud crater, natural and artificial causes, etc. Mud volcanoes mainly develop in basins with fast sedimentation rates and lateral compression tectonic effects on the continental margin. Their formation and eruption are related to underground rich oil and natural gas, earthquakes and volcanic activities. The eruption of a mud volcano requires three elements: a mud source, an ascending channel and pressurized gas. In addition, mud volcanoes are of great significance to the study of regional tectonic, biogeochemistry, geological disasters, global climate change and oil and gas exploration. Today, they have become one of the hot spots in earth science research.

There are more than 40 mud volcano areas developed on land and more than 20 mud volcano areas developed on the seafloor. The number of mud volcanoes in each development area ranges from a few to more than a hundred. In general, there are more than 2,000 mud volcanoes on land and on the seafloor in the world, distributed in China, Italy, the United States, Azerbaijan, Iran and Romania. In addition, the gases released by land mud volcanoes are mainly methane, as well as nitrogen, carbon dioxide and hydrogen sulfide, while the gases released by submarine mud volcanoes include nitrogen, carbon dioxide, hydrocarbons, sulfides and inert gases.

Azerbaijan mud volcano group (above, sourced from the Internet), mud volcanoes and sulfur crystals near the vents in the Santa Felicita area of ​​Naples, Italy (bottom left first and second from the left, original images), Liyushan mud volcano in Pingtung County, Taiwan Province, China (bottom right second, sourced from the Internet) and Aiqigou No. 2 mud volcano in Xinjiang Uyghur Autonomous Region, China (bottom right first, original image)

my country's mud volcanoes are mainly distributed in Xinjiang Uygur Autonomous Region, Qinghai Province, Taiwan Province and Sichuan Province. Among them, Xinjiang Uygur Autonomous Region is the main distribution area of ​​my country's mud volcanoes, and mud volcanoes are mainly distributed in Wusu (Baiyanggou and Aiqigou), Dushanzi and Horgos. The strata in these mud volcano outcropping areas are mainly muddy sandstones, rich in multi-layer groundwater, which usually has the characteristics of high lamination pressure, high mineralization, and high natural gas or oil content.

Spatial distribution map and digital elevation model map of some mud volcano groups in Xinjiang Uygur Autonomous Region (Image source: Jilin-1 high-resolution satellite earth observation image and National Geographic Information Public Service Platform)

The Wusu mud volcano group is located in the hilly area on the northern slope of the Tianshan Mountains in my country, at the intersection of the Hongche Fault and the Urumqi West-West Gunan Fault (among which, the Urumqi West-West Gunan Fault was active at least in the late Pleistocene), mainly including the Baiyanggou mud volcano group and the Aiqigou mud volcano group. Among them, the Baiyanggou mud volcano group is located about 43 kilometers southwest of Wusu City, Xinjiang Uygur Autonomous Region. All mud volcanoes are concentrated in an area of ​​less than 0.5 square kilometers near Baiyanggou Town, scattered on hillsides and valleys with a radius of about half a kilometer. The Quaternary strata in the distribution area of ​​the mud volcano group are mainly divided into sand dunes, aeolian loess and sandstone. There are more than 100 mud craters at most, and currently 21-40 are erupting. The largest diameter mud crater is about 1.6 meters, which is also the largest mud volcano group in my country. These mud craters are mostly round or oval, and the gushing natural gas and mud are constantly churning in the craters. The more violent mud volcanoes erupt more than 60 times per minute. The mud is thick and smooth, with a slightly salty taste. Some mud volcanoes have oil floating on the surface of the mud, as if the earth is boiling. Scientists have determined that the mud is rich in methane, radon, hydrogen and carbon dioxide. The temperature of the mud gushing out of the Baiyanggou mud volcano group is so low that it feels cold when you put your hands in it. Locals also call it the "cool volcano."

Mud volcano No. 1 in the Aiqigou mud volcano group in Xinjiang Uygur Autonomous Region (original image)

Most of the mud volcanoes in the Aiqigou mud volcano group are isolated cones, and the Quaternary strata in the distribution area of ​​the mud volcano group are mainly sand, mud and sub-sand soil. Among them, two mud volcanoes are about 9 meters high and about 10 meters apart. They are rare "twin mud cone mud volcanoes" in my country. Compared with the Baiyanggou mud volcano group, its eruption products are more viscous and its appearance is similar to that of volcanoes formed by magma. The surface of the mud pile is covered with dense flow marks and scour marks. These marks are intertwined, resembling the "big tree roots" that entangle the two mud volcanoes. From a distance, the two mud volcanoes are like sisters wearing long skirts that drag on the ground, which are particularly eye-catching among the mountains. The mud volcano on the north side of the two mud volcanoes is slightly taller, with a vent diameter of about 3.2 meters; while the mud volcano on the south side is slightly smaller, with a vent diameter of about 3 meters. The eruption of the Aiqigou mud volcano group is more intense than that of the Baiyanggou mud volcano group, erupting once every ten minutes. When the volcano erupts, the vent of the mud volcano is like a boiling pot, with colorful oil-stained mud rolling from the middle of the vent to the surrounding areas, making gurgling sounds. At the edge of the vent of the mud volcano, there is a gap formed by the overflow of mud. The gushing mud extends outward in circles like ripples of water, and slowly flows out along the gap of the mud volcano crater.

Aiqigou Mud Volcanoes No. 1 and No. 2 in Xinjiang Uygur Autonomous Region (top left, original image), Baiyanggou Mud Volcano Group No. 1 (top right, original image), Dushanzi Mud Volcano Group (bottom left, image from the Internet), and cold springs in Madagascar (bottom right, original image)

The Dushanzi mud volcano group is located in Huangtu Mountain, about 1 km southwest of the Dushanzi mining area of ​​the Xinjiang Petroleum Administration Bureau, near the Hongche Fault, with an altitude of about 950 meters. A large-scale eruption occurred in 1995. The Quaternary strata in the distribution area of ​​the mud volcano group are mainly composed of aeolian sand dunes, aeolian loess and gravel sand, and the Neogene strata are mainly composed of sandstone, siliceous limestone, sandy conglomerate and shell limestone. There are four main eruption vents in the Dushanzi mud volcano group, which are concentrated within 500 square meters of the top platform of Huangtu Mountain. The maximum diameter of the mud volcano vent is about 1.4 meters, and the smallest diameter is about 5 centimeters. The viscous mud ejected is mostly gray-green with a slight smell of oil. The gushing mud forms a cone-shaped hill on the surface. The diameter of the bottom of the mud volcano group exceeds 10 meters, and the surface is a dry and cracked mud block. At present, most vents have stopped spewing mud, but a small amount of gas is still overflowing.

Compared with the cold springs in Madagascar in southeastern Africa, the mud volcanoes in Xinjiang Uygur Autonomous Region show a unique "mellowness". If the super-active volcano Campi Flegrei in Italy, the large active volcano Stromboli in Italy and the large active volcano Tianchi in Changbai Mountain show the power and beauty of nature, then the mud volcanoes in Xinjiang Uygur Autonomous Region show the wonder and uniqueness of nature!

Italy's Campi Flegrei super active volcano (left), Italy's Stromboli large active volcano (middle) and China's Changbai Mountain Tianchi large active volcano (right) (all original images)

Mud volcanoes can be divided into natural mud volcanoes (formed by geological action) and artificial mud volcanoes (induced by oil and gas extraction or drilling) according to their causes. Among them, natural mud volcanoes can be roughly divided into two types of causes: the formation of one type of mud volcano is related to sedimentation, that is, there is a thick layer of plastic organic-rich sediments underground, which contains a large amount of water and hydrocarbon gases. They often have great pressure. When encountering cracks or faults in the crust movement, the water and gas under high pressure will expand and rise. The mud and rock debris around the rising channel are ejected to the surface, accompanied by jets (including water vapor) and mud, and sometimes fire (gases such as methane spontaneously ignite at high temperatures) to form mud volcanoes. This type of mud volcano is mostly formed in areas with developed oil and gas reservoirs, such as the mud volcanoes in the Baku oil field in Azerbaijan, the Dushanzi and Baiyanggou mud volcanoes in the Xinjiang Uyghur Autonomous Region of China, and are also called "gasoline volcanoes". Therefore, in a sense, mud volcanoes are an important sign for finding oil and gas reservoirs; the formation of another type of mud volcano is related to volcanic activity, such as the mud volcanoes in Yellowstone Park in the United States, which are not only numerous but also large in scale.

Globally, the eruption intensity of most mud volcanoes is not severe and will not have a significant impact or damage to the surrounding natural environment. A few mud volcanoes will have extremely strong eruptions, and the large amount of gas ejected will have a certain impact or obvious destructive effect on the surrounding environment. The eruption of mud volcanoes will also be accompanied by flames and high-temperature mud ejection, and the erupted mud can cover more than several square kilometers, causing significant damage to surrounding towns, villages and infrastructure. In October 2004, a magnitude 6.2 earthquake occurred in Taiwan Province, my country. Before the earthquake, mud volcanoes in Kaohsiung County erupted several times, and the frequency and intensity of the eruptions increased significantly. Shortly after the earthquake, relevant departments in Taiwan Province began to conduct gas geochemical and seismic observations on the mud volcano group near the seismogenic fault. Similarly, scientists have studied the correlation between mud volcanoes and seismic activity in the northern Tianshan region of Xinjiang, my country, and believe that mud volcano activity is a manifestation of crustal movement during the process of strengthening tectonic stress in the Tianshan region. In short, although mud volcanoes do not have the magnificent natural landscapes of mountains formed by violent tectonic movements and volcanoes formed by magma, their formation mechanism and the relationship between resources and disasters have attracted much attention from scientists. Moreover, mud volcanoes are also an important research object to reveal the migration of underground fluids, oil and gas generation, and tectonic activities.

Savushen Mountain in Sichuan Province in winter (left) and the aurora at night (center) and Tianchi Volcano in Changbai Mountain, Jilin Province in spring (right) (original images)

In addition, the mud that erupts from mud volcanoes usually contains minerals and trace elements such as calcium, magnesium, iron, barium, copper, and zinc, and has certain antibacterial and oil-control effects. The microporous structure of volcanic mud can absorb oil, dirt, and aged keratin on the surface of the skin, and can play a physical cleaning role, similar to the principle of activated carbon, suitable for oily skin or T-zone (forehead and nose) care. In short, the application of volcanic mud in the field of beauty is not without basis, but has a certain scientific basis, but its effect and applicability still need to be combined with personal skin quality and scientific usage methods.

Colombian mud volcano bathing pool (Photo from the Internet)

This issue of science popularization ends! Friends, see you next time!

References in this issue:

[1] Huang Huagu, Di Pengfei, Chen Duofu. Global distribution and research progress of mud volcanoes[J]. Bulletin of Mineralogy, Petrology and Geochemistry, 2011, 30(2), 190-197.

[2] Zhou Yongsheng, He Changrong, Yang Xiaosong. Water and deformation mechanism in the ductile shear zone of the middle crust[J]. Science China: Earth Sciences, 2008, 38(7), 819-832.

[3] Pan Xiaodong, Xu Zhitao, Li Mengmeng, et al. Multiple natural disasters and ecological security evaluation report on the construction of Changbai Mountain's whole-region tourism transportation system[R]. Jilin Provincial Seismological Bureau, 2022.

[4] Guo Weiying, Ma Jin, Shan Xinjian. Research on the topographic and geomorphic differences and annual variation characteristics of infrared brightness temperature in active fault zones[J]. Progress in Geophysics, 2008, 23(5), 1437-1443.

[5] Li Mengmeng, Xu Zhitao, Sun Liying, et al. Research progress on intermediate-acid volcanic rocks in the cone-forming period of Tianchi volcano in Changbai Mountain[C]. Seismological and Geomagnetic Observation and Research, 2021, 42(2), 2.

[6] YAO Yuan. Late Quaternary interaction between different structures and seismogenic tectonic model in the western section of the North Tianshan foreland thrust belt[D]. Institute of Geology, China Earthquake Administration, PhD dissertation, 2024.

[7] Xu Zhitao, Sun Liying, Li Zhongwei, et al. Origin of Early Pleistocene basaltic lava in Longgang volcanic area and its tectonic significance: Evidence from Rb-Sr isotope dating, elemental geochemistry and Pb isotope[J]. Journal of Jilin University: Earth Science Edition, 2023, 53(3), 887-903.

[8] Gao Yuan, Wang Yongli, Zheng Guodong, et al. Geochemical characteristics of natural gas in Dushanzi mud volcano, Junggar Basin, Xinjiang [J]. Acta Geoscientia Sinica, 2012, 33(6), 989-994.

[9] Ye Xiqing, Xu Zhitao*, Sun Liying, et al. Origin and tectonic significance of Miocene basalt in the Laohushan volcanic area, Jilin Province[J]. Earth Science, 2024, 49(4), 1352-1366.

[10] Xu Shiyang, Chai Shaofeng, Yin Guanghua, et al. Study on the mechanism of earthquake sinkhole disaster in the mud volcano development area of ​​Xinjiang[J]. Chinese Journal of Earthquake Engineering, 2021, 43(1), 190-197.

[11] Yan Donghan, Xu Zhitao*, Xu Yueren, et al. 14C dating of the Siping section of the Yitong-Shulan fault zone and its tectonic significance[J]. Journal of Geodesy and Geodynamics, 2022, 42(8), 835-839.

[12] Li Zhongwei, Xu Zhitao, Yan Donghan, et al. Project report on active fault exploration in the Siping section of the Yitong-Shulan fault in the northern extension of the Tanlu fault zone based on high-resolution remote sensing interpretation technology[R]. Jilin Provincial Seismological Bureau, 2020.

[13] Fan Hailong, Peng Chuankai, Yu Xinqi, et al. Geochemical characteristics and mud sources of the Wusu mud volcano in Xinjiang [J]. Geological Bulletin, 2017, 36(8), 190-197.

[14] Ye Xiqing, Xu Zhitao, Pan Xiaodong, et al. Geodynamic mechanism of the Middle Pleistocene trachyte eruption at Tianchi volcano in Changbai Mountain[C]. Seismological and Geomagnetic Observation and Research, 2023, 44(S1), 38-41.

[15] Zhu Tingting, Lu Xiancai, Zhu Youhua, et al. Preliminary study on the origin of the Wushanshan mud volcano in southwestern Taiwan [J]. Chinese Journal of Petrology and Mineralogy, 2009, 28(5), 465-472.

[16] Ye Xiqing, Xu Zhitao, Li Mengmeng, et al. Research report on the age and geochemical characteristics of the Middle Pleistocene trachyte magma eruption in the southwest of Julong Hot Spring, Tianchi Volcano[R]. Jilin Provincial Seismological Bureau, 2023.

[17] Du Jianguo, Zhou Xiaocheng, Li Ying, et al. Response of the northern Tianshan mud volcano to the Xinyuan-Hejing Ms6.6 earthquake on June 30, 2012[J]. Acta Seismologica Sinica, 2013, 35(6), 12.

[18] Li Yanhao, Jiang Hanchao, Xu Hongyan, et al. Analysis of triggering factors of landslide in the upper reaches of Minjiang River in Sichuan[J]. Seismology and Geology, 2015, 37(4), 1147-1161.

[19] Liu Chunru, Yin Gongming, Han Fei, et al. Application of quartz ESR dating to dating of Quaternary continental sediments[J]. Quaternary Sciences, 2016, 36(5), 1236-1245.

[20] Jiang, HC, Zhong, N., Li, YH, et al. A continuous 13.3ka record of seismogenic dust events in lacustrine sediments in the eastern Tibetan Plateau[J]. Scientific Reports, 2017, 7(1), 15686.

[21] Wang,

[22] Xu, ZT, Sun, LY, Ye, XQ, et al. U–Pb geochronology and geochemistry of dikes in the Changbaishan Tianchi volcanic field (NE China) and their relations with the coeval Jingbohu and Longgang monogenetic volcanic fields[J]. International Geology Review, 2023, 66(3), 814-831.

[23] Li, Niu., Huang, HG, Chen, DF Fluid sources and chemical processes inferred from geochemistry of pore fluids and sediments of mud volcanoes in the southern margin of the Junggar Basin, Xinjiang, northwestern China[J]. Applied Geochemistry, 2014, 46, 1-9.

[24] Xu, ZT, Ye, XQ, Pan, XD, et al. Geochemistry of apatites from preshield and postshield basalts and their petrogenetic implications: A case study of the Naitoushan basalt and Heishigou dike in the Changbaishan Tianchi volcano, NE China[J]. Mineralogy and Petrology, 2024, 118, 345-366.

[25] Zhang. K., Liu, ZP, Xu, ZT, et al. Microbial and hydrothermal dolomite formation in Early Cretaceous lacustrine sediments in Yin'e Basin: Insights from petrology and geochemistry[J]. Sedimentary Geology, 2024, 471, 106739.

[26] Li, MM, Xu, ZT*., Ventura, G., et al. Geochronology and petrogenesis of Early Pleistocene dikes in the Changbai Mountain volcanic field (NE China) based on geochemistry and Sr-Nd-Pb-Hf isotopic compositions[J]. Frontiers in Earth Science, 2021, 9, 729905.

[27] Gu, GH, Hu, H., Pan, XD, et al. Hydrogen emission characteristics of Changbaishan Volcano: Spatial and temporal distribution and genesis[J]. Geothermics, 2025, 127, 103269.
